Ribbon Powder Mixer Food Grade Ribbon Blender

Introduction: This is a Ribbon powder mixer food grade ribbon blender ,designed to mix all kinds of dry powder .It consists of one U-shaped horizontal mixing tank and two groups of mixing ribbon: outer ribbon displace the poweder from the end to the center and inner ribbon move the powder from the center to the ends .This counter-current action results in homogeneous mixing!

What is a ribbon blender and how does it work?

1. Principle of operation

Ribbon Mixers are a specific type of powder blenders that consist of 2 parts mounted on a central shaft . The mixing medium often consists of inner and outer helical ribbons that are designed to move material both inwards and outwards. The external helical ribbons pull product from the sides of the mixer into the middle and the internal ribbons push the product back to the sides. The back-and-forth folding motion of the materials to be blended creates a convective mixing pattern.

The ribbons are designed to have precise gap tolerances between the walls of the mixer. In some instances, they can even be designed with soft material wipers to help keep product from building up on the sides. The drive mechanism often consists of a belt drive for the powder transmission between the motor and gear box. This arrangement would use a system of flexible belts and pulleys to produce the desired speed and torque required for the specific mixing application. However, more manufacturers are starting to use direct drives via gear motors that utilize a motors low inertia rotor to specifically match the gearbox unit. The advantage of this arrangement means less maintenance over the life of the industrial mixer.

Make sure to understand the required volume capacity of the mixer you are in need of. Knowing the bulk densities of the ingredients to be mixed is crucial to understanding the required capacity of your mixer, and more importantly the needed motor power required to mix your batches properly. Most standard design mixers will work just fine with a product bulk density of 35 lbs./ft³. However, once you start mixing denser batches the need for heavy duty motors and gear ratio changes will also be required.

2. Main benefits of ribbon blenders

Ribbon mixers are the most versatile and widely used type of powder blending machine in the market. They often are most commonly used for solids on solids mixing but can also be used for applications involving coating a dry particle with a liquid ingredient, or even particle absorption of a liquid addition. Rarer applications do allow for slurry and liquid particle suspension mixes with careful design and consideration to detail.

Because of the convective mixing pattern of the ribbon blender, short and fast mixing cycles are possible often ranging from a few minutes up to 20 minutes (depending on the volume and complexity of the formula). Considering the fast-mixing cycles of these bulk solids blenders you would think the ribbons run at a very high RPM, however this is not so. The ribbon agitators typically run no faster then 300 feet/min tip speed. This low speed creates a gentle folding action of the particles to be mixed. Therefore, this allows use on fragile and friable materials while preserving the particle integrity.

Standard Specifications:
    Model ABFRB200 ABFRB300ABFRB500ABFRB1000ABFRB1500ABFRB2000
 Full  Volume200L300L500L1000L1500L2000L
Turning Speed46rpm46rpm46rpm46rpm46rpm46rpm
Mixing Vessel3mm3mm3mm4mm5mm6mm
Wall  Plate6mm8mm8mm8mm8mm12mm
Main Shaft 57*676*676*889*8102*8114*10
Mixing Blade 6mm6mm6mm8mm10mm12mm
Whole Length140015301700200024002600
Whole Width90010001200130014001500
Total Height145015501700196020502200
Total Weight250KGS350KGS500KGS700KGS1000KGS1300KGS
Total Power4KW5.5KW7.5KW11KW15KW22KW
Air Consumption4-6Bars
Power Supply3 P  AC208-415V  50/60HZ
